Monitor: 15inch
Probe connector: DCU20/30 Two probe connectors; DCU50 one connectors
Two USB Ports
One video port
One S-video port
One VGA port
One network port
1. Imaging Modes:
l B, B|B, 4B, B|M, M
l Color Doppler (CF), Power Doppler (PDI), Directional Power Doppler (DPDI)
l Pulsed Wave Doppler (PW)
l Continuous Wave Doppler (CW) (Optional)
l B+CF (Dual Images)
l M+CF
l Anatomic M
l B+PW (Duplex), B+CFM/PDI/DPDI+PW (Triplex)
l High Pulse Repetition Frequency (HPRF)
l Tissue Harmonic Imaging (THI), Pulse Inversion Tissue Harmonic Imaging (iTHI)
l Tissue Specific Imaging
l Convex Extended Imaging (Optional)
l Linear Trapezoid Imaging (Optional)
l Spatial Compound Imaging (Optional)
l 3D/4D Imaging (Optional)
2. Scanning Method: electronic linear, electronic convex, electronic micro-convex, electronic phased array, 3D probe, scanning depth: 2-30cm
3. Color Doppler:
l PRF variable: 0.6-20kHz
l Wall filter settings: ≥ 5 steps
l Angle steering for linear transducers: ±5°, ±10°, ±15°
l Real-time spatial filter: ≥ 4 values
l CFM palette: ≥10 maps
l PDI palette: ≥10 maps
l B/Color priority control
l Color threshold control
l CFM baseline control
l Doppler frequency selection: ≥ 4 values
l color frame averaging
l Transparent Color Mapping (TCM)
4. Pulsed Wave Doppler:
l PRF variable: 0.6-20 kHz
l Wall filter settings: ≥ 10 steps
l Angle steering for linear transducers: ±5°, ±10°, ±15°
l Real-time trace line with automatic calculation of spectrum parameters
l Stereo sound: volume control
l PWD palette: ≥10 maps
l Doppler frequency selection: ≥ 4 values
5. Processing:
l Multi-beamform Imaging
l High Line Density scan mode for better resolution
l 8 sliders TGC Control
l Dynamic Range: ≥120 dB
l Overall gain control
l M mode sweep speed control
l Acoustic power control
l Variable frame averaging
l Advanced gamma control
l Scan direction, rotation, up-down controls
l Negative / positive control
l Echo enhancement control
l Noise rejection function
l Speckle reduction
6. Image and video: AVI, JPG, BMP, PNG, TIF, DCM (DICOM) etc.
7. General Measurements and Calculations: Distance, Length, Area, Circumference, Volume, Angle, Stenosis %, A/B Ratio, Velocity, Pressure Gradient (PG), Acceleration, Resistivity Index (RI), Heart Rate, Velocity Time Integral (VTI), etc.
8. Measurements and Calculations Software Packages: Obstetrics, Gynecology, Abdominal, Urology, Endocrinology, Vascular, Cardiology, etc.
9. 3D/4D module included
10. Expansion interfaces:
l VGA, TV Interface
l USB Interface
l RJ-45 Network interface
l Support DeskJet printer, LaserJet printer, video printer
